ICX 7150-C12P in router mode
- Mark as New
- Bookmark
- Subscribe
- Mute
- Subscribe to RSS Feed
- Permalink
- Report Inappropriate Content
04-27-2023 07:12 AM
I am trying to get a replacement ICX 7150 switch to connect however, I believe it is in router mode instead of switch. I have read the multiple threads on how to resolve this however, I cannot telnet in. Can someone please walk me through how to resolve this? I do not have technical experience with switches and how to telnet in so please make this as simple as possible. Thank you!
- Mark as New
- Bookmark
- Subscribe
- Mute
- Subscribe to RSS Feed
- Permalink
- Report Inappropriate Content
04-27-2023 07:36 AM
Hi Rleschber
Ack and Noted. Thank you for reaching out to us.
Could you please let me know if you are from Lennar Homes ?
I have attached a link below that will help you to console to the switch and access switch CLI using putty . Follow the steps in case you are facing an issue . Please upload the picture of the image to this post .
Link :
Once you have access to switch using CLI. Please help us with below command.
- Switch> enable
- Switch#show run | include telnet
- Switch#show telnet config
If you facing any issue or seeing a error when you follow any steps in the link. Please upload the picture of the error using the below option
Also please upload the picture of front panel of the switch using the above option .
I hope the above steps help you.
Thanks
- Mark as New
- Bookmark
- Subscribe
- Mute
- Subscribe to RSS Feed
- Permalink
- Report Inappropriate Content
04-27-2023 07:49 AM
Hi, I was able finally telnet into the device and it appears both the primary and secondary code is router. I do not see the switch code in either. I do have a Lennar home. How do I resolve this?
- Mark as New
- Bookmark
- Subscribe
- Mute
- Subscribe to RSS Feed
- Permalink
- Report Inappropriate Content
04-27-2023 07:50 AM
Here is a screenshot.
- Mark as New
- Bookmark
- Subscribe
- Mute
- Subscribe to RSS Feed
- Permalink
- Report Inappropriate Content
04-27-2023 09:02 AM
Hi Rleschber
Ack and Noted. Thanks for reverting back.
Below is the link to firmware 8095h :
After downloading the firmware from above link
- Unzip the folder
- Go to 7150 folder -> Images folder -> choose "SPS08095hufi.bin" for the upgrade methods given below
Refer below links to upgrade to SPS firmware
How to Upgrade a Switch ICX-7150-C12P using a USB flash drive
How to upgrade a Switch ICX7150-C12P via TFTP (YouTube link)
Software Recovery method
I hope the above links help you.
Thanks
