telnet@ICX7150-C12-Router>show lldp neighbors
LLDP is not running
telnet@ICX7150-C12-Router>show lldp neighbors details
Invalid input -> details
Type ? for a list
telnet@ICX7150-C12-Router>show poe
Power Capacity: Total is 124000 mWatts. Current Free is 93200 mWatts.
Power Allocations: Requests Honored 13 times
Port Admin Oper ---Power(mWatts)--- PD Type PD Class Pri Fault/
State State Consumed Allocated Error
--------------------------------------------------------------------------
1/1/1 On On 4100 15400 802.3af Class 3 3 n/a
1/1/2 On On 3800 15400 802.3af Class 3 3 n/a
1/1/3 On Non-PD 0 0 n/a n/a 3 n/a
1/1/4 On Off 0 0 n/a n/a 3 n/a
1/1/5 On Non-PD 0 0 n/a n/a 3 n/a
1/1/6 On Off 0 0 n/a n/a 3 n/a
1/1/7 On Off 0 0 n/a n/a 3 n/a
1/1/8 On Off 0 0 n/a n/a 3 n/a
1/1/9 On Off 0 0 n/a n/a 3 n/a
1/1/10 On Off 0 0 n/a n/a 3 n/a
1/1/11 On Off 0 0 n/a n/a 3 n/a
1/1/12 On Off 0 0 n/a n/a 3 n/a
--------------------------------------------------------------------------
Total 7900 30800
telnet@ICX7150-C12-Router>show who
Console connections (by unit number):
1 established, privilege super-user
3 day(s) 18 hour(s) 33 minute(s) 45 second(s) in idle
Telnet server status: Enabled
Telnet connections (inbound):
1 established, client ip address 192.168.1.119, privilege super-user
using vrf default-vrf.
you are connecting to this session
23 second(s) in idle
2 closed
3 closed
4 closed
5 closed
6 closed
7 closed
8 closed
9 closed
10 closed
11 closed
12 closed
13 closed
Telnet connections (outbound):
14 closed
15 closed
16 closed
17 closed
18 closed
SSH server status: Disabled
SSH copy-received-cos status: Disabled
SSH connections:
SSH connections (inbound):
1 closed
2 closed
3 closed
4 closed
5 closed
SSH connection (outbound):
6 closed
7 closed
8 closed
9 closed
10 closed
11 closed
12 closed
13 closed
--More--, next page: Space, next line: Return key, quit: Control-c
telnet@ICX7150-C12-Router>show version
Copyright (c) 2017 Ruckus Wireless, Inc. All rights reserved.
UNIT 1: compiled on Nov 20 2018 at 00:20:22 labeled as SPR08080d
(29819448 bytes) from Secondary SPR08080d.bin
SW: Version 08.0.80dT213
Compressed Boot-Monitor Image size = 786944, Version:10.1.14T225 (mnz10114)
Compiled on Thu Nov 15 12:59:22 2018
HW: Stackable ICX7150-C12-POE
==========================================================================
UNIT 1: SL 1: ICX7150-C12-2X1G POE 12-port Management Module
Serial #:FEK3801R0EM
Software Package: ICX7150_BASE_L3_SOFT_PACKAGE
Current License: 2X1G
P-ASIC 0: type B160, rev 11 Chip BCM56160_B0
==========================================================================
UNIT 1: SL 2: ICX7150-2X1GC 2-port 2G Module
==========================================================================
UNIT 1: SL 3: ICX7150-2X10GF 2-port 20G Module
==========================================================================
1000 MHz ARM processor ARMv7 88 MHz bus
8192 KB boot flash memory
2048 MB code flash memory
1024 MB DRAM
STACKID 1 system uptime is 3 day(s) 18 hour(s) 34 minute(s) 41 second(s)
The system started at 00:07:51 GMT+00 Sat Jan 01 2000
The system : started=cold start
telnet@ICX7150-C12-Router>show log
Syslog logging: enabled ( 0 messages dropped, 0 flushes, 0 overruns)
Buffer logging: level ACDMEINW, 81 messages logged
level code: A=alert C=critical D=debugging M=emergency E=error
I=informational N=notification W=warning
Static Log Buffer:
Jan 1 00:02:03:I:System: Stack unit 1 POE PS 1, Internal Power supply with 124000 mwatts capacity is up
Dynamic Log Buffer (4000 lines):
Jan 4 18:31:06:I:Security: telnet login by un-authenticated telnet user from src IP 192.168.1.119 from src MAC 086a.c516.099f to USER EXEC mode
Jan 4 15:53:14:I:Security: telnet terminated by un-authenticated telnet user from src IP 192.168.1.119 from src MAC 086a.c516.099f from USER EXEC mode
Jan 4 15:26:07:I:COPY COMPLETED
Jan 4 15:25:32:I:COPY FLASH FLASH START
Jan 4 15:25:13:I:COPY BUNDLE IMAGE COMPLETED
Jan 4 15:25:05:I:COPY BOOTROM IMAGE FROM BUNDLE START
Jan 4 15:24:37:I:COPY APPLICATION IMAGE FROM BUNDLE START
Jan 4 15:20:34:I:COPY IMAGE TO FLASH START
Jan 4 15:18:04:I:COPY IMAGE TO FLASH START
Jan 4 15:16:15:I:COPY IMAGE TO FLASH START
Jan 4 15:00:07:I:Security: telnet login by un-authenticated telnet user from src IP 192.168.1.119 from src MAC 086a.c516.099f to PRIVILEGED EXEC mode
Jan 4 14:59:36:I:Security: telnet login by un-authenticated telnet user from src IP 192.168.1.119 from src MAC 086a.c516.099f to USER EXEC mode
Jan 4 14:59:05:D:next hop router 192.168.1.119 moved from port 1/1/1 to port 1/1/5
Jan 4 14:56:27:D:next hop router 192.168.1.119 moved from port 1/1/5 to port 1/1/1
Jan 3 16:02:30:I:System: Interface ethernet 1/1/1, state down
Jan 3 15:45:45:I:System: Interface ethernet 1/1/1, state up
Jan 3 15:45:41:I:System: Interface ethernet 1/1/1, state down
Jan 3 15:45:34:I:System: Interface ethernet 1/1/2, state up
Jan 3 15:45:29:I:System: Interface ethernet 1/1/2, state down
Jan 3 15:44:58:I:System: Interface ethernet 1/1/1, state up
Jan 3 15:44:52:I:System: Interface ethernet 1/1/1, state down
Jan 3 15:44:46:I:System: Interface ethernet 1/1/2, state up
Jan 3 15:44:39:I:System: Interface ethernet 1/1/2, state down
Jan 2 13:31:44:I:System: PoE: Power disabled on port 1/1/5 because of detection of non-PD. PD detection will be disabled on port.
Jan 2 13:31:43:I:System: Interface ethernet 1/1/5, state up
Jan 2 13:31:37:I:System: Interface ethernet 1/1/5, state down
Jan 1 00:05:16:D:DHCPC: TFTP unable to download running-configuration
Jan 1 00:04:58:D:DHCPC: sending TFTP request for bootfile name brocade.cfg
Jan 1 00:04:41:D:DHCPC: sending TFTP request for bootfile name default.cfg
Jan 1 00:04:23:D:DHCPC: sending TFTP request for bootfile name ICX7150-C12-Router.cfg
Jan 1 00:04:06:D:DHCPC: sending TFTP request for bootfile name ICX7150-C12-Routerc0c5.209c.7235.cfg
Jan 1 00:03:49:D:DHCPC: sending TFTP request for bootfile name ICX7150-C12-Routerc0c5.209c.7235-config.cfg
Jan 1 00:03:32:D:DHCPC: sending TFTP request for bootfile name ICX7150-C12-Routerc0c5.209c.7235-config.cfg
Jan 1 00:03:16:D:DHCPC: sending TFTP request for bootfile name ICX7150-C12-Routerc0c5.209c.7235-config.cfg
Jan 1 00:03:13:I:System: Interface ethernet 1/1/2, state up
Jan 1 00:03:11:I:System: Interface ethernet 1/1/1, state up
Jan 1 00:03:09:I:System: Interface ethernet 1/1/2, state down
Jan 1 00:03:07:I:System: Interface ethernet 1/1/1, state down
Jan 1 00:03:00:D:DHCPC: sending TFTP request for bootfile name ICX7150-C12-Routerc0c5.209c.7235-config.cfg
Jan 1 00:02:44:D:DHCPC: sending TFTP request for bootfile name ICX7150-C12-Routerc0c5.209c.7235-config.cfg
Jan 1 00:02:30:I:System: Interface ethernet 1/1/2, state up
Jan 1 00:02:28:I:System: Interface ethernet 1/1/1, state up
Jan 1 00:02:28:I:DHCPC: ICX7150-C12-Router configured with ip-address 192.168.1.247; subnet mask 255.255.255.0 on port 1/1/5
Jan 1 00:02:28:D:DHCPC: sending TFTP request for bootfile name ICX7150-C12-Routerc0c5.209c.7235-config.cfg
Jan 1 00:02:28:I:PORT: 1/1/5, added ip address 192.168.1.247 by un-authenticated user from console session.
Jan 1 00:02:21:I:System: PoE: Power enabled on port 1/1/2.
Jan 1 00:02:21:I:System: PoE: Power enabled on port 1/1/1.
Jan 1 00:02:03:I:System: Stack unit 1 POE PS 1, Internal Power supply with 124000 mwatts capacity is up
Jan 1 00:02:02:I:System: Interface ethernet 1/1/5, state up
Jan 1 00:02:02:I:System: Interface ethernet 1/1/3, state up
Jan 1 00:02:00:I:PKI: Trustpoint DEVICE_TRUSTPNT: error: File not loaded, Manufacturing certificate expired.
Jan 1 00:01:59:I:System failed to boot from primary !!
Jan 1 00:01:59:I:System: Cold start
Jan 1 00:01:58:D:DHCPC: starting dhcp client service on 656 port(s)
