1 ACCEPTED SOLUTION
Hi @LennerHelp
Greetings!!!
Thank you for the response and the information you shared.
This may be because your switch may be running on the Routing code (SPR). The Switch should run on the Switching code (SPS) to avoid these issues for Lennar home users. Due to a power outage/power spike, the Switch boots up on the other partition which may be running on a ‘Routing Code’ results in causing this issue.
As I can see from the output you shared, your Switch may be booted up on the secondary partition which is running on Routing code (SPR) as highlighted in the below screenshot.
Please Enter the below commands in CLI to fix this issue:
Note: Hit Enter to accept each command
enable
copy flash flash secondary
boot system flash secondary yes
Example:
VIDEO LINK AS REFERENCE: https://www.youtube.com/watch?v=Eem1IBgYaWc
ICX7150-24P Router>enable (hit enter to accept the command)
ICX7150-24P Router#copy flash flash secondary (hit enter to accept the command and wait: until the flash finished)
ICX7150-24P Router#boot system flash secondary yes (hit enter to accept the command: the switch will reboot)
Please check let me know if you have any queries in this regard.
Thank you again for your patience.
Best regards,
Imran Sanadi
RUCKUS Lennar Home Community.
Understood. I will perform your suggested steps shortly. See below screen when I try to boot from primary yesterday which is why I thought primary was corrupted. Thanks.
Hi. Yes still same error.
Actually, it looks like it is showing switch firmware now.
Hi @LennerHelp
Thank you for the response and the information you shared.
From the screenshot you shared we can see, now your Switch is on SPS code on both the partitions.
Please follow the below steps to Upgrade your Switch to the recommended stable version
The recommended stable versions are 8095g (08.0.95g)
The Upgrade path would be 8080d>>8080f>>8095g
Below are the options or methods to perform the Upgrade on the switch: You could choose any one of these.
1st Option:
1. In this option, we will use a pen drive or USB flash drive in which we move the files to the pen drive and connect it to the Switch then through CLI we execute the commands to upgrade the Switch using the following guide as a reference:
How to Upgrade a Switch ICX-7150-C12P using a USB flash drive
2nd Option:
2. The following guide is an example of an upgrade via TFTP server, by using an application (FREE) to send files or upload remote files to a device, in our case, we will use it to update a new version to the Switch, basically it will send the image version remotely from the computer to the switch.
How to upgrade a Switch ICX7150-C12P via TFTP
3rd Option:
3.In this option we Upgrade the Switch from the Web Interface (GUI) of switch.
Try to access your switch from a web browser by pasting the below URL in http or https form whichever that works.
https://0.0.0.0 or http://0.0.0.0 (IP address of Switch. 0.0.0.0 is just as an example)
As you can access CLI, I would suggest you follow the 2nd option.
Please let me know if you have any queries in this regard.
Thank you again for your patience.
Best regards,
Imran Sanadi
RUCKUS Lennar Home Community.
