ICX7150 Switch routing code issue, slow and intermittent internet

asaad1972

Hi,

I have issues with my Ruckus network. I had a power down issue and Cox issues. Now my Cox network works fine but my Ruckus network has many issues. Internet is very slow or not working at all. My Unleashed app is showing ICX7150-C12-Router and "connecting (discovery)" with red font.

I read many other forums that all point to the routing code issue. I tried to connect with a Putty command line to my switch but the CLI doesn't accept the commands listed on other forums, such as "show flash", "copy flash flash secondary", "boot system flash secondary yes". I am attaching a screenshot of my Putty CLI window.

I see 3 IP addresses for Ruckus Wireless since I have one switch and two APs. One IP doesn't connect while the second doesn't accept the "enable" command. The third one is the one that I am showing the screenshot from above.

I also tried to connect to the switch with a USB cable but I couldn't find instructions to connect with the serial interface.

Please advise on how to reconfigure the switch out of this Routing mode.

Thanks

Ashraf

Find more posts tagged with

Accepted answers

imran.sanadi@commscope.com

Hi @asaad1972

Thank you for your response and the update.

The Unleashed dashboard appears to be functioning normally based on the screenshot you provided.

Please let me know if you encounter any issues with connectivity or performance.

Thank you once again for your patience and understanding.

Best regards,

Imran Sanadi
RUCKUS Lennar Home Community

All comments

imran.sanadi@commscope.com

Hi @asaad1972

I hope this message finds you well.

Thank you for reaching out to the RUCKUS Lennar Home Community.

We appreciate your patience as we work to resolve the issues with your RUCKUS setup.

Based on the information provided, it appears you are experiencing intermittent internet connectivity due to the Routing Code.

We apologize for any inconvenience this may have caused and are committed to assisting you promptly.

It seems that you are currently seeing the ‘ruckus>’ prompt in the CLI, which is associated with Unleashed rather than the ICX-7150-C12P Switch. To confirm you are accessing the Switch CLI, you should see prompts such as:

-ICX7150-C12 Router>
-ICX7150-C12 Switch>

Additionally, you should see the Switch Dashboard, as shown in the screenshot below, to verify the Switch IP Address.

If you can access the CLI of the Switch, please refer to the following RUCKUS Lennar Knowledge Base article for guidance on fixing the Routing code issue:

/kb/articles/2-fixing-ruckus-icx-7150-c12p-switch-routing-code-spr-issue-using-command-line-interface-cli

Please let me know if you have any questions or if further assistance is needed.

Thank you once again for your patience and understanding.

Best regards,

Imran Sanadi
RUCKUS Lennar Home Community

asaad1972

Hi Imran,

Thanks for your reply!

I see 3 IP addresses associated with Ruckus as shown below. I tried each one of them and I am not seeing the command line or the switch screen shot you shared with me. How do I see the IP address for the switch?

Regards

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

Thank you for your response and update.

Since the IP address 192.168.0.75 appears to be inactive, it may be related to the Switch. Please try rebooting your ISP (Internet Service Provider) modem-router combo device by unplugging it from the power outlet, waiting a few moments, and then plugging it back in. After performing this reboot, scan for IP addresses again to check if the Switch IP address becomes active or any new active IP address assigned to the Switch.

Please confirm if this resolves the issue.

Thank you once again for your patience and understanding.

Best regards,

Imran Sanadi
RUCKUS Lennar Home Community

asaad1972

Hi Imran,

I followed these steps but I am still getting 192.168.0.75 inactive state while the two other IPs are active. Here is a screenshot of the switch box in case you find any clue. The Ruckus network is working at the moment but very slow.

Thanks

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

Thank you for the response and the update.

If there is no active IP address of the Switch, the only option is to get Console CLI access. Please try getting console access to the Switch and try to access CLI.

Here is a guide on how to access to the Switch via console (cable access between your PC to the ICX 7150-C12P) in this case we need a USB type C to USB standard OR Console cable Rj45 to USB (Any one cable- please refer the guide)

How to console in the ICX-7150-C12P

https://community.ruckuswireless.com/t5/RUCKUS-Support-for-Lennar-Homes/How-to-console-in-the-ICX-7150-12c-using-a-Windows-Machine/td-p/46759

Please let me know if you have any queries in this regard.

Thank you again for your patience and understanding.

Best regards,

Imran Sanadi

RUCKUS Lennar Home Community.

asaad1972

Hi Imran,

I tried to connect to the USB-C connector on the switch to my laptop USB-C port after installing the driver. Unfortunately, I still can't connect to the switch and I can't see the CP210x USB in device manager when I connect the cable. Do you know if USB-C to USB-C cable should work since my laptop doesn't have USB-A ports?

Thanks

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

Thank you for the response and the update.

Both ends of Type-C may have some issues.

You can check using an ethernet cable connecting to the alternate console port on the Switch (Port no. 15 in the below screenshot) that does the same function as the USB type-c port on the Switch.

Once again, please make sure to download the zip drive for the file below & "extract all". Once it's extracted, run the file, the driver should be installed using the 2 links below.

Link 1: https://support.ruckuswireless.com/software/1414-brocade-ruckus-7150-usb-serial-driver-windows

Link 2: silabs.com/developers/usb-to-uart-bridge-vcp-drivers?tab=downloads

Please check and let me know if that works.

Thank you again. We appreciate your patience and understanding.

Best regards,

Imran Sanadi

RUCKUS Lennar Home Community.

imran.sanadi@commscope.com

Hi @asaad1972

Greetings!!!

I trust this message finds you well.

I kindly request an update on the status of the issue so that we may proceed further with resolving it.

Thank you.

Best regards,
Imran Sanadi
RUCKUS Lennar Home Community

asaad1972

Hi Imran,

I used USB-C to USB-A cable and USB-A to USB-C adaptor to connect the switch to my laptop and I was able to access the switch command line. It was indeed in Router mode and I followed the commands you recommended in the beginning. The switch now is showing "switch" mode not router. Thank you so much for helping me resolve the issue!

The only question I still have is that the speed I am getting from Ruckus AP's is still limited to under 85Mbps, even if I am very close to the AP, while my ISP WiFi is giving me 700Mbps if I am close to the WiFi router. Is this speed limit expected with my Ruckus devices? Or is there other fixes I can do to get the full speed it can offer?

Thanks

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

Greetings!!!
Thank you for the response and the update.

Great! Good to know that the SPR issue is now resolved.

To address the speed issues, please unplug the R510 Access Points and ISP Router's cable from the current ports and plug them to any other ports 1 through 12 (Refer to the below screenshot) on the RUCKUS ICX-7150-C12P Switch. Then check the speeds.

Please try these steps and let me know if the issue is resolved or if you have any further questions.

Thank you for your patience and understanding.

Best regards,

Imran Sanadi
RUCKUS Lennar Home Community

asaad1972

Hi Imran,

I unplugged all cable and re-plugged only the ISP and APs cables on different slots. I still get slow ~80Mbps wifi speed from the AP's.

Thanks

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

Thank you for your response and the information provided.

We may need to review the configuration of the Access Points (AP) via the Unleashed system.

Please follow the instructions below and provide the requested details:

1. Log in to your Unleashed system using a laptop web browser, either via the Master AP IP Address or https://unleashed.ruckuswireless.com/

2. Take separate screenshots for each Access Point, similar to the example provided below to check the AP port speed.

3. Additionally, perform a SpeedFlex test to measure the speeds between the Master and Member Access Points. Refer to the screenshot below for the SpeedFlex process.

Please provide the requested screenshots and test results at your earliest convenience.

Thank you again for your patience and cooperation.

Best regards,

Imran Sanadi
RUCKUS Lennar Home Community

asaad1972

Hi Imran,

Here are the screenshots.

Thanks

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

Greetings!

Thank you for your response and the information you provided.

Based on the screenshot output, everything appears to be normal. To further troubleshoot, please create a new WLAN/SSID and try. We suggest configure a separate 5GHz and 2.4G radio network on your Unleashed Access Point to minimize any potential wireless interference with the each radios.

For guidance on creating a new WLAN/SSID, please refer to the following resources:

- Creating a New Wireless WLAN (SSID):

https://community.ruckuswireless.com/t5/RUCKUS-Support-for-Lennar-Homes/Creating-a-New-Wireless-WLAN-SSID/td-p/47049

-Video Tutorial: https://www.youtube.com/watch?v=eSl_8rs1QnU

Please check and let me know and If you have any questions or need further assistance, please let me know.

Thank you again for your patience.

Best regards,
Imran Sanadi
RUCKUS Lennar Home Community

asaad1972

Thanks Imran!

I did create two new WLAN's, one on 5GHz and another on 2.4GHz. Unfortunately, the Wifi speed is still limited or 80Msps or less, closer to the APs.

Regards

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

Thank you for your response and update.

At this stage, the next step would be to perform a factory reset of the Access Points and reconfigure them with a new Wi-Fi network/SSID. For detailed instructions on how to carry out the factory reset, please refer to the following RUCKUS Lennar Knowledge Base article:

/kb/articles/7-how-to-factory-reset-your-ruckus-r510-r310-access-point-and-set-up-a-new-wi-fi-network-ssid

Please follow the instructions outlined in the article, and do not hesitate to reach out if you require any further assistance.

Thank you once again for your patience and cooperation.

Best regards,

Imran Sanadi
RUCKUS Lennar Home Community

asaad1972

Hi Imran,

Thanks for sharing this information. I followed the steps to factory reset my AP and create a new Wifi but the new Wifi doesn't seem to be working. I repeated the process twice but got t he same problem. The AP power LED is flashing green and doesn't turn solid green as you see in the attached image. Also, I am not able to connect to the new Wifi on my phone or laptop. I am attaching the picture showing the new Wifi having a continuous progress icon next to it that doesn't go away and I lose internet connectivity.

Thanks

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

Greetings!!!

Thank you for the response and the update.

Could you please log into the Switch CLI, please execute the following commands, and provide the outputs?

enable

show version

show flash

show inline power

show inline power detail

show ip address

show interface brief

show lldp neighbors detail

Please share the command outputs or screenshots if you encounter any issues or errors during these steps.

Feel free to reach out if you have any questions or require further assistance.

Thank you for your cooperation and patience.

Best regards,

Imran Sanadi

RUCKUS Lennar Home Community

asaad1972

Hi Imran,

I am attaching the output for the commands you requested as screen shots below. This time I was able to connect remotely to the switch IP address. Also, now I see the old WLAN networks not the new one I created after the factory reset. This happened after power cycling the switch.

Thanks

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

Greetings!

Thank you for your response and the update.

The command output appears to be normal. However, it seems that your switch is running an older version. Before proceeding with an upgrade, could you please provide the following information?

1. How many RUCKUS Access Points do you have?

2. If you are still seeing the old Wi-Fi network, please try forgetting the network or toggling your Wi-Fi off and on again to check if the new Wi-Fi network appears.

If the new network still does not appear, it may indicate that the factory reset process was not successful.

Please review these steps and let me know your findings.

Best regards,

Imran Sanadi
RUCKUS Lennar Home Community

imran.sanadi@commscope.com

Hi @asaad1972

Greetings!!!

I trust this message finds you well.

I kindly request an update on the status of the issue so that we may proceed further with resolving it.

Thank you.

Best regards,
Imran Sanadi
RUCKUS Lennar Home Community

asaad1972

Hi Imran,

I have two APs and I disconnected one per instructions. I repeated the factory reset again just to make sure it works. I can now connect to the new Wifi I created but the speed is still slow ~90Msps. Also I wasn't able to manage the new network in the Unleashed App. I am attaching some images for the new network behavior.

Thanks

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

We greatly appreciate your continued engagement.

We suggest you upgrading your Switch and Access Points to a recommended.

Regarding the Switch upgrade process, we recommend transitioning to version 08.0.95g, identified as the stable version for Lennar Home users.

To facilitate this transition, we have recently introduced an upgrade tool tailored to ensure a seamless process. Utilizing this tool is straightforward: users simply need to input the IP Address, Username, and password associated with the Switch into the software interface.

For your convenience, please find the necessary resources below:

1. Download the Upgrade software for Windows: Link: Upgrade Software for Windows

2. Access the Upgrade Software User Manual: Link: Upgrade Tool User Guide for Lennar SmartHome users

For the RUCKUS Access Points upgrade process, please refer to the below RUCKUS Lennar Knowledge Base self-help article.

/kb/articles/9-ruckus-unleashed-access-points-upgrade-process-to-the-recommended-firmware-version

Should you require any assistance throughout the process, please do not hesitate to reach out. Your satisfaction is our priority, and we are here to support you every step of the way.

Please let me know the progress after the upgrade.

Thank you once again for your patience and cooperation.

Best regards,

Imran Sanadi
RUCKUS Lennar Home Community

asaad1972

Hi Imran,

Thank you for your dedicated support!

I followed the instructions to upgrade the switch and the AP. Both were successful but I had to create a new WLAN since the AP upgrade removed my previous WLAN.

Unfortunately, the Wifi speed is still limited to 80Mbps or less on my phone and laptop. Maybe this is the H/W limitation of my switch and AP? What is the expected Wifi speed for my system?

Thanks

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

Thank you for your response and the update.

I apologize for any inconvenience this may have caused.

The RUCKUS R510 APs support wireless network speeds of up to 1.3 Gbps, while the ICX-7150-C12P Switch supports speeds of 10 Gbps or higher.

Please consider the following steps once:

1. Clear Your Browser Cache: Sometimes, old or corrupted files in your cache can cause loading issues. Clearing your browser’s cache might help.

2. Try a Different Browser: If you’re using one browser, try accessing the site with another (e.g., Chrome, Firefox, Edge) to see if the issue persists.

3. Check Your Internet Connection: Ensure your internet connection is stable and not experiencing high latency or interruptions.

4. Disable Browser Extensions: Some browser extensions can interfere with site performance. Try disabling them temporarily to see if it improves the loading time.

5. Update Your Browser: Make sure your browser is up to date with the latest version, as updates can resolve compatibility issues.

6. Try Accessing from a Different Network: If possible, attempt to access the site from a different network (e.g., a mobile hotspot) to rule out network-specific issues.

7. Check ethernet cables: Check ethernet cables connected to the Switch and Access Points if they are functioning properly.

8. Restart Your Router/Modem: Sometimes, restarting your network hardware can resolve connectivity issues.

Please check the above-mentioned steps once and check.

Thank you again. We appreciate your patience and understanding.

Best regards,

Imran Sanadi

RUCKUS Lennar Home Community.

asaad1972

Thanks Imran.

I have tried multiple devices and phones and they all give me a slow speed. I recall we tried the speed between the two APs and it was around 400Mbps.

I still have my second AP disconnected. How can I connect and configure this other AP with the new WLAN? How to assign it as a member since the first AP would be the master AP?

Thanks

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

I hope this message finds you well.

Thank you for your prompt response and the update.

After performing a factory reset connecting only ONE Access Point, and connecting back the disconnecting AP back to the Switch port after reset, should synchronize with the existing Unleashed system, with the reset AP acting as the master and the others as slaves.

To ensure both Access Points are part of the same Unleashed system, they must be running the same Unleashed version. To verify this, please follow these steps:

1. Perform an IP scan to identify the IP addresses assigned to both APs.

Refer the RUCKUS Lennar Knowledge Base self-help article on hoe to perform and identify Unleashed IP address.

/kb/articles/10-how-to-find-the-ip-address-of-the-ruckus-devices-switch-and-aps-using-ip-scanner-free-applications

2. Enter these IP addresses into a web browser and check if the Unleashed dashboard is visible.

3. If the dashboard is accessible, attempt to log in.

Please confirm once you have completed these steps.

Thank you for your patience and cooperation.

Best regards,

Imran Sanadi
RUCKUS Lennar Home Community

asaad1972

Hello Imran,

I connected the second AP and it seems to be recognized by the system. I can only login to one of the IP addresses but one doesn't respond. I am attaching here a few images of the system.

Thanks

Ashraf

Screenshot 2024-09-05 102427.jpg

imran.sanadi@commscope.com

Hi @asaad1972

Greetings!!!

Thank you for your recent communication and the provided information.

I see from the web unleashed system screenshot both the Access Points are synced.

From the screenshot you shared, the RUCKUS Switch is not added into the Unleashed system. Since the Switch has not been integrated into the Unleashed system, please follow the outlined procedure below to manually add.

Switch Configuration:
1. Ensure that management approval is enabled on the Switch.

https://docs.commscope.com/bundle/unleashed-200.14-onlinehelp/page/GUID-42B53C1F-032B-4341-9735-16F8049BE157.html

Access Points (Unleashed) Configuration: (Refer to the below steps and screenshots)
1. Access the Unleashed dashboard.

2. Remove the current non-working Switch.

3. Navigate to the "Add" function on the dashboard.

4. Enter the IP address and password for the ICX switch (ICX-7150-C12P). This IP address is the same one used to access the Switch CLI.

5. Use the same username and password for Switch authentication as you would for accessing the Switch via web or CLI (e.g., Putty).

6. Data synchronization may take several minutes. Once completed, the status should indicate "connected" on the dashboard.

Please review the dashboard post-synchronization to ensure the Switch has been successfully integrated.

Should you have any questions or require further assistance, feel free to reach out.

Thank you once again for your attention to this matter.

Best regards,

Imran Sanadi
RUCKUS, Lennar Home Community

asaad1972

Thanks Imran!

Here is the new screenshot of the switch and I think it should be working fine now. With regards to the rest of the ethernet cables connected to the switch and some devices and rooms in my house, do I need to reconfigure any of them to use the new setup? or will they work without any changes?

Thanks

Ashraf

Screenshot 2024-09-05 111355.jpg

imran.sanadi@commscope.com

Hi @asaad1972

Thank you for your response and the update.

From the screenshot you provided, it appears that the RUCKUS ICX-7150-C12-P Switch has not yet been added to the Unleashed system.

Please follow the instructions outlined in my previous communication to add it.

As for the other devices, there is no need to reconfigure them; they should continue to function as expected.

If you have any questions or need further assistance, please feel free to reach out.

Thank you for your patience and understanding.

Best regards,

Imran Sanadi
RUCKUS, Lennar Home Community

asaad1972

Hi Imran,

Sorry, I may have shared the wrong screenshot because I did follow the instructions to remove and re-add the switch. Here is a screenshot that shows one switch is connected. Is this working as expected now?

Thanks

Ashraf

Screenshot 2024-09-05 114227.jpg

imran.sanadi@commscope.com

Hi @asaad1972

Thank you for your response and the update.

The Unleashed dashboard appears to be functioning normally based on the screenshot you provided.

Please let me know if you encounter any issues with connectivity or performance.

Thank you once again for your patience and understanding.

Best regards,

Imran Sanadi
RUCKUS Lennar Home Community

asaad1972

Hi Imran,

Thank you so much for your dedicated support and patience! At this moment, I have a working network and I believe we have done everything possible. My ISP Wi-Fi is fast enough on the top floor and Ruckus WLAN is working fine for the devices downstairs. We can close this issue now and I appreciate your help!

Thanks

Ashraf

imran.sanadi@commscope.com

hi @asaad1972

Thank you for your response and the update.

Could you please confirm whether you are experiencing improved speed with the RUCKUS devices, or if the performance remains the same?

Thank you once again for your patience and understanding.

Best regards,

Imran Sanadi
RUCKUS, Lennar Home Community

asaad1972

Hi Imran,

The Wifi speed is still the same even after upgrading the system. The speed between the APs seems to be high still but the Wifi on my different devices is limited to <90Msps.

Thanks

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

Thank you for your response and the update.

To compare the speeds between the Access Point Wi-Fi and the Switch, please connect an Ethernet cable from your laptop to any 1 of the 12 ports on the Switch (refer to the screenshots below). Then, check the speed through your laptop’s web browser using this wired Internet connection.

Please review and let me know the results.

Thank you once again for your patience and understanding.

Best regards,

Imran Sanadi
RUCKUS Lennar Home Community

asaad1972

Hi Imran,

The speed via an ethernet cable from the switch to my desktop is around 900Msps as shown below.

We had a power outage last night and the Wifi speed is better now from different spots in my house, as shown below. So the full power cycle of the system may have helped as well.

Thanks

Ashraf

asaad1972

Actually, the 319 Msps speed was the ISP Wifi, closer to the router, but the 105Msps & 185Msps are from the AP Wifi.

Thanks

Ashraf

imran.sanadi@commscope.com

Hello @asaad1972

Greetings!!!

I hope this message finds you well.

Thank you for your response and the update.

It appears that the Access Points (APs) are now functioning normally. The observed speed variations may be attributed to several factors, such as RF interference and the distance between the device and the AP.

To clarify, a 2.4 GHz connection generally provides longer range but at lower speeds, whereas 5 GHz frequencies offer faster speeds but cover shorter distances. The choice between 2.4 GHz and 5 GHz is often determined automatically by the end device (such as phones, PCs, Ring doorbells, Mac devices, iPhones). Additionally, network configuration (Wi-Fi/SSID/WLAN) may specify whether the network supports only 2.4 GHz, only 5 GHz, or both.

It's also worth noting that many electronic devices and appliances, such as microwaves, baby monitors, security cameras, garage door openers, and phones, operate on the 2.4 GHz frequency, which can contribute to interference. Screenshot below for the reference.

Please let me know if you have any further questions or concerns.

Thank you once again for your patience and understanding.

Best regards,

Imran Sanadi
RUCKUS Lennar Home Community

asaad1972

Thanks Imran for all your help!

Best regards

Ashraf

imran.sanadi@commscope.com

Hi @asaad1972

Thank you for the response.

We appreciate your time and patience on this case.

Thank you again for contacting RUCKUS Lennar Home Community and feel free to contact us for future queries.

Have a great day ahead!!!

Best regards,

Imran Sanadi

RUCKUS Lennar Home Community.
